AUQ200 3000 Kg Polyurethane Wheel

BH-G200K 900 Kg Zinc Castor Fixed Cast Iron 200mm x 50mm

$105.35 (Incl. GST)

Technical Specifications

• -Castor Type- Fixed
• -Load Capacity- 900 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Cast Iron
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 50mm
• -Overall Height- 245mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 140mm x 110mm
• -Mounting Plate Hole Centres- 105mm x 75mm-80mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- N/A

Heavy industrial cast iron castor. Suitable for high loads in demanding applications, such as metal working workshops, foundries and other application where tyred wheels fail.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BH-GTH200K 900 Kg Zinc Castor Fixed P/U on Cast Iron 200mm x 50mm

$127.10 (Incl. GST)

Technical Specifications

• -Castor Type- Fixed
• -Load Capacity- 900 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 50mm
• -Overall Height- 245mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 140mm x 110mm
• -Mounting Plate Hole Centres- 105mm x 75mm-80mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- N/A

Heavy industrial polyurethane tyred cast iron castor. Suitable for demanding high load applications and can be power towed. Polyurethane tyre will protect floor surface and reduce noise.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BP20050B 300 Kg Blue Rubber Wheel

$51.35 (Incl. GST)

Technical Specifications

• -Load Capacity- 300 Kg
• -Wheel Diameter- 200mm
• -Wheel Material- Polypropylene
• -Tyre Material- Blue Rubber
• -Tread Width- 45mm
• -Hub Length (unsleeved)- 56mm
• -Hub Length (sleeved)- 62mm
• -Bore Diameter (Unsleeved)- 20mm
• -Sleeved Bore Diameter Options- 12.7mm (1/2")
• -Sleeve Type- Top Hat Pair
• -Bearing Type- Ball Bearings

Heavy Industrial blue rubber wheel only (fitted with ball bearings - and supplied with 2 top hat spacers)

Delivery or in-store pickup available.

BS-GTH 202K 1600 Kg Zinc Castor Rigid P/U on Cast Iron 200mm x 80mm

$269.20 (Incl. GST)

Technical Specifications

• -Castor Type- Fixed
• -Load Capacity- 1600 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 80mm
• -Overall Height- 255mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 175mm x 140mm
• -Mounting Plate Hole Centres- 140mm x 105mm
• -Mounting Plate Hole Diameter- 14mm
• -Swivel Radius (inc. brake if fitted)- N/A

Heavy industrial polyurethane tyred cast iron castor. Suitable for demanding high load applications. Polyurethane tyre will protect floor surface and reduce noise.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BS-GTH 252K 1800 Kg Zinc Castor Rigid P/U on Cast Iron 200mm x 80mm

$421.80 (Incl. GST)

Technical Specifications

• -Castor Type- Fixed
• -Load Capacity- 1800 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 80mm
• -Overall Height- 305mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 175mm x 140mm
• -Mounting Plate Hole Centres- 140mm x 105mm
• -Mounting Plate Hole Diameter- 14mm
• -Swivel Radius (inc. brake if fitted)- N/A

Heavy industrial polyurethane tyred cast iron castor. Suitable for demanding high load applications. Polyurethane tyre will protect floor surface and reduce noise.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

CFQ200 45 Kg Foamed Urethane Wheel

$45.25 (Incl. GST)

Technical Specifications

• -Load Capacity- 45 Kg
• -Wheel Diameter- 200mm
• -Wheel Material- Black Nylon
• -Tyre Material- Foamed Urethane
• -Tread Width- 45mm
• -Hub Length (unsleeved)- 50mm
• -Hub Length (sleeved)- N/A
• -Bore Diameter (Unsleeved)- 8mm
• -Sleeved Bore Diameter Options- N/A
• -Sleeve Type- N/A
• -Bearing Type- Ball Bearing

Replacement wheelchair front castor wheels. Foamed polyurethane on nylon centre.

Delivery or in-store pickup available.

CFQ200/CPH 45 Kg Black Paint Castor Swivel Foamed Urethane 200mm x 45mm

$93.85 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 45 Kg
• -Brake Type- N/A
• -Mounting Type- 12.7mm Bolt-Hole
• -Wheel Material- Foamed Urethane
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Black Paint
• -Wheel Diameter X Tread Width- 200mm x 45mm
• -Overall Height- 237mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- N/A
• -Swivel Radius (inc. brake if fitted)- 144mm

Wheelchair specific castor. EVA foam wheel non-marking

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

G200/20K 1000 Kg Cast Iron Wheel

$69.60 (Incl. GST)

Technical Specifications

• -Load Capacity- 1000 Kg
• -Wheel Diameter- 200mm
• -Wheel Material- Cast Iron
• -Tyre Material- Cast Iron
• -Tread Width- 50mm
• -Hub Length (unsleeved)- 60mm
• -Hub Length (sleeved)- 61.3mm
• -Bore dia. (Unsleeved)- 20mm
• -Sleeved Bore dia. Options- 12.7mm (1/2")
• -Sleeve Type- Top Hat Pair
• -Bearing Type- Ball Bearings

Delivery or in-store pickup available.

GTH200/20K 1000 Kg Polyurethane Wheel

$93.30 (Incl. GST)

Technical Specifications

• -Load Capacity- 1000 Kg
• -Wheel Diameter- 200mm
• -Wheel Material- Cast Iron
• -Tyre Material- Polyurethane
• -Tread Width- 50mm
• -Hub Length (unsleeved)- 60mm
• -Hub Length (sleeved)- 65.1mm
• -Bore Diameter (Unsleeved)- 20mm
• -Sleeved Bore Diameter Options- 12.7mm(1/2")
• -Sleeve Type- Top Hat Pair
• -Bearing Type- Ball Bearings

Heavy Industrial polyurethane tyred cast iron wheel only - fitted with ball bearings

Delivery or in-store pickup available.

GTHN200/25H7 200mm x 50mm Polyurethane on Cast Iron Drive Wheel w/ H7 Keyway

$171.05 (Incl. GST)

Technical Specifications

• -Load Capacity-  900 Kg
• -Wheel Diameter-  200mm
• -Wheel Material-  Cast Iron
• -Tyre Material-  Polyurethane
• -Tread Width-  50mm
• -Hub Length (unsleeved)-  60mm
• -Hub Length (sleeved)- N/A
• -Bore Diameter (Unsleeved)-  25mm w/ H7 Keyway
• -Sleeved Bore Diameter Options- N/A
• -Sleeve Type- N/A
• -Bearing Type- N/A

Delivery or in-store pickup available.

GTHN202/35H7 200mm x 80mm Polyurethane on Cast Iron Drive Wheel w/ H7 Keyway

$262.40 (Incl. GST)

Technical Specifications

• -Load Capacity-  1400 Kg
• -Wheel Diameter-  200mm
• -Wheel Material-  Cast Iron
• -Tyre Material-  Polyurethane
• -Tread Width-  80mm
• -Hub Length (unsleeved)-  80mm
• -Hub Length (sleeved)- N/A
• -Bore Diameter (Unsleeved)-  35mm w/ H7 Keyway
• -Sleeved Bore Diameter Options- N/A
• -Sleeve Type- N/A
• -Bearing Type- N/A

Delivery or in-store pickup available.

HBA200 250 Kg Blue Rubber Wheel

$43.10 (Incl. GST)

Technical Specifications

• -Load Capacity- 250 Kg
• -Wheel Diameter- 200mm
• -Wheel Material- Black Nylon
• -Tyre Material- Blue Rubber
• -Tread Width- 32mm
• -Hub Length (unsleeved)- 60mm
• -Hub Length (sleeved)- 61.3mm
• -Bore Diameter (Unsleeved)- 20mm
• -Sleeved Bore Diameter Options- 13mm
• -Sleeve Type- Spacer Tube
• -Bearing Type- Plain

Heavy Industrial blue rubber/nylon wheel - plain bore (supplied with spacer sleeve)

(HBR200 shown in photographs.)

Delivery or in-store pickup available.
