CBQ100G 100kg Blue Rubber Wheel

$14.00 (Incl. GST)

Technical Specifications:

• Load Capacity: 100kg
• Wheel Diameter: 100mm
• Wheel Material: Black Nylon
• Tyre Material: Blue Rubber
• Tread Width: 30mm
• Hub Length (unsleeved): 40mm
• Hub Length (sleeved): N/A
• Bore Diameter (Unsleeved): 8mm
• Sleeved Bore Diameter Options: N/A
• Sleeve Type: N/A
• Bearing Type: Ball Bearings

Light Industrial blue rubber wheel only (fitted with ball bearings)

Download Specifications PDF

Delivery or in-store pickup available.

BP10050B 150kg Blue Rubber Wheel

$19.60 (Incl. GST)

Technical Specifications:

• Load Capacity: 150kg
• Wheel Diameter: 100mm
• Wheel Material: Polypropylene
• Tyre Material: Blue Rubber
• Tread Width: 35mm
• Hub Length (unsleeved): 56mm
• Hub Length (sleeved): 62mm
• Bore Diameter (Unsleeved): 17mm
• Sleeved Bore Diameter Options: 12.7mm (1/2")
• Sleeve Type: Spacer Tube
• Bearing Type: Ball Bearings

Heavy Industrial blue rubber wheel only (fitted with ball bearings - and supplied with 2 top hat spacers)

Download Specifications PDF

Delivery or in-store pickup available.

BPUQ100BHTB 130kg Black Series Castor Swivel Bolt Hole Total Brake P/U on Nylon 100mm x 30mm

$22.00 (Incl. GST)

Technical Specifications:

• Castor Type: Swivel
• Load Capacity: 130kg
• Brake Type: Total Brake
• Mounting Type: 13mm Bolt Hole
• Wheel Material: P/U on Nylon
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Painted Black
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 130mm
• Axle Type: Bolted
• Mounting Plate Dimensions: N/A
• Mounting Plate Hole Centres: N/A
• Mounting Plate Hole Diameter: 13mm
• Swivel Radius (inc. brake if fitted): 111mm

Light industrial decorative castor with a painted black finish, wheel is non marking black polyurethane. Suitable applications include furniture, displays, shopfittings etc.

Download Specifications PDF

Delivery or in-store pickup available.

CBQ100G/MZF 100kg Zinc Castor Fixed N/A Blue Rubber 100mm x 30mm

$22.50 (Incl. GST)

Technical Specifications:

• Castor Type: Fixed
• Load Capacity: 100kg
• Brake Type: N/A
• Mounting Type: Plate
• Wheel Material: Blue Rubber
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 135mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 96mm x 78mm
• Mounting Plate Hole Centres: 80/76mm x 60/44mm
• Mounting Plate Hole Diameter: 9mm Slotted
• Swivel Radius (inc. brake if fitted): N/A

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Download Specifications PDF

Delivery or in-store pickup available.

CBQ100G/MZP 100kg Zinc Castor Swivel N/A Blue Rubber 100mm x 30mm

$26.70 (Incl. GST)

Technical Specifications:

• Castor Type: Swivel
• Load Capacity: 100kg
• Brake Type: N/A
• Mounting Type: Plate
• Wheel Material: Blue Rubber
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 135mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 96mm x 78mm
• Mounting Plate Hole Centres: 80/76mm x 60/44mm
• Mounting Plate Hole Diameter: 9mm Slotted
• Swivel Radius (inc. brake if fitted): 91mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Download Specifications PDF

Delivery or in-store pickup available.

CBQ100G/MZPN 100kg Zinc Castor Swivel N/A Blue Rubber 100mm x 30mm

$26.70 (Incl. GST)

Technical Specifications:

• Castor Type: Swivel
• Load Capacity: 100kg
• Brake Type: N/A
• Mounting Type: Plate
• Wheel Material: Blue Rubber
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 135mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 95mm x 70mm
• Mounting Plate Hole Centres: 76/67mm x 44mm
• Mounting Plate Hole Diameter: 9mm Slotted
• Swivel Radius (inc. brake if fitted): 91mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Download Specifications PDF

Delivery or in-store pickup available.

CBQ100G/MZH 100kg Zinc Castor Bolt-Hole N/A Blue Rubber 100mm x 30mm

$26.70 (Incl. GST)

Technical Specifications:

• Castor Type: Bolt-Hole
• Load Capacity: 100kg
• Brake Type: N/A
• Mounting Type: 12.7mm Bolt-Hole
• Wheel Material: Blue Rubber
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 135mm
• Axle Type: Bolted
• Mounting Plate Dimensions: N/A
• Mounting Plate Hole Centres: N/A
• Mounting Plate Hole Diameter: N/A
• Swivel Radius (inc. brake if fitted): 91mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Download Specifications PDF

Delivery or in-store pickup available.

827O 140kg 20mm Round Groove Wheel

$29.00 (Incl. GST)

Technical Specifications:

• Groove Type: 20mm Round Groove
• Load Capacity: 140kg
• Wheel Diameter: 80mm
• Wheel Material: Steel
• Finish: Zinc Plated
• Tyre Material: Steel
• Tread Width: 26mm
• Groove Width: 21mm
• Groove Depth: 9mm
• Hub Length (unsleeved): 12mm
• Hub Length (sleeved): 34mm
• Bore Diameter (unsleeved): 17mm
• Sleeved Bore Diameter Options: 14mm
• Sleeve Type: Top Hat Pair
• Bearing Type: Ball Bearing
• Axle Bolt/Nut Supplied? M14 x 60mm & Nut

Machined steel "O" round groove wheels, for use with sliding gate floor track or 20mm bar.

Delivery or in-store pickup available.

CBQ100G/MZPTB 100kg Zinc Castor Swivel Total Brake Blue Rubber 100mm x 30mm

$33.90 (Incl. GST)

Technical Specifications:

• Castor Type: Swivel
• Load Capacity: 100kg
• Brake Type: Total Brake
• Mounting Type: Plate
• Wheel Material: Blue Rubber
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? Yes
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 100mm x 30mm
• Overall Height: 135mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 96mm x 78mm
• Mounting Plate Hole Centres: 80/76mm x 60/44mm
• Mounting Plate Hole Diameter: 9mm Slotted
• Swivel Radius (inc. brake if fitted): 128mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Download Specifications PDF

Delivery or in-store pickup available.

BH-G150K 900kg Zinc Castor Fixed N/A Cast Iron 150mm x 50mm

$75.00 (Incl. GST)

Technical Specifications:

• Castor Type: Fixed
• Load Capacity: 900kg
• Brake Type: N/A
• Mounting Type: Plate
• Wheel Material: Cast Iron
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? No
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 150mm x 50mm
• Overall Height: 197mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 140mm x 110mm
• Mounting Plate Hole Centres: 105mm x 75mm-80mm
• Mounting Plate Hole Diameter: 11mm
• Swivel Radius (inc. brake if fitted): N/A

Heavy industrial cast iron castor. Suitable for high loads in demanding applications, such as metal working workshops, foundaries and other application where tyred wheels fail.

Delivery or in-store pickup available.

BH-GTH150K 750kg Zinc Castor Fixed N/A P/U on Cast Iron 150mm x 50mm

$93.20 (Incl. GST)

Technical Specifications:

• Castor Type: Fixed
• Load Capacity: 750kg
• Brake Type: N/A
• Mounting Type: Plate
• Wheel Material: P/U on Cast Iron
• Wheel Bearing Type: Ball Bearing
• Threadguard Fitted? No
• Frame Finish: Zinc
• Wheel Diameter X Tread Width: 150mm x 50mm
• Overall Height: 197mm
• Axle Type: Bolted
• Mounting Plate Dimensions: 140mm x 110mm
• Mounting Plate Hole Centres: 105mm x 75mm-80mm
• Mounting Plate Hole Diameter: 11mm
• Swivel Radius (inc. brake if fitted): N/A

Heavy industrial polyurethane tyred cast iron castor. Suitable for demanding high load applications and can be power towed. Polyurethane tyre will protect floor surface and reduce noise.

Delivery or in-store pickup available.
