Grooved Wheels

Sort by:
613 100 Kg 6mm Round Groove Wheel

Wheels

$22.40 (Incl. GST)
613 100 Kg 6mm Round Groove Wheel

613 100 Kg 6mm Round Groove Wheel

$22.40 (Incl. GST)

Technical Specifications:

  • Groove Type: 6mm Round Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 60mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 13mm
  • Groove Width: 6mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 17mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? No

Machined steel rope groove pulley, suits 6mm wire rope.

Delivery or in-store pickup available.


More Info
813 100 Kg 6mm Round Groove Wheel

Wheels

$23.90 (Incl. GST)
813 100 Kg 6mm Round Groove Wheel

813 100 Kg 6mm Round Groove Wheel

$23.90 (Incl. GST)

Technical Specifications:

  • Groove Type: 6mm Round Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 80mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 13mm
  • Groove Width: 6mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 17mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? No

Machined steel rope groove pulley, suits 6mm wire rope.

Delivery or in-store pickup available.


More Info
618V 80 Kg V Groove Wheel

Wheels

$25.30 (Incl. GST)
618V 80 Kg V Groove Wheel

618V 80 Kg V Groove Wheel

$25.30 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 80 Kg
  • Wheel Diameter: 60mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 18mm
  • Groove Width: 12mm
  • Groove Depth: 5mm
  • Hub Length (unsleeved): 14mm
  • Hub Length (sleeved): 24mm
  • Bore Diameter (unsleeved): 12mm
  • Sleeved Bore Diameter Options: 10mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M10 x 45mm & Nut

Machined steel "V" groove wheel, for use with folded angle tracks.

Delivery or in-store pickup available.


More Info
718V 100 Kg V Groove Wheel

Wheels

$29.85 (Incl. GST)
718V 100 Kg V Groove Wheel

718V 100 Kg V Groove Wheel

$29.85 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 70mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 18mm
  • Groove Width: 12mm
  • Groove Depth: 5mm
  • Hub Length (unsleeved): 14mm
  • Hub Length (sleeved): 24mm
  • Bore Diameter (unsleeved): 12mm
  • Sleeved Bore Diameter Options: 10mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M10 x 45mm & Nut

Machined steel "V" groove wheel, for use with folded angle tracks.

Delivery or in-store pickup available.


More Info
913 100 Kg 6mm Round Groove Wheel

Wheels

$30.90 (Incl. GST)
913 100 Kg 6mm Round Groove Wheel

913 100 Kg 6mm Round Groove Wheel

$30.90 (Incl. GST)

Technical Specifications:

  • Groove Type: 6mm Round Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 90mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 13mm
  • Groove Width: 6mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 17mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? No

Machined steel rope groove pulley, suits 6mm wire rope.

Delivery or in-store pickup available.


More Info
1013 100 Kg 6mm Round Groove Wheel

Wheels

$33.90 (Incl. GST)
1013 100 Kg 6mm Round Groove Wheel

1013 100 Kg 6mm Round Groove Wheel

$33.90 (Incl. GST)

Technical Specifications:

  • Groove Type: 6mm Round Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 100mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 13mm
  • Groove Width: 6mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 17mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? No

Machined steel rope groove pulley, suits 6mm wire rope.

Delivery or in-store pickup available.


More Info
820V 140 Kg V Groove Wheel

Wheels

$35.00 (Incl. GST)
820V 140 Kg V Groove Wheel

820V 140 Kg V Groove Wheel

$35.00 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 140 Kg
  • Wheel Diameter: 80mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 20mm
  • Groove Width: 14mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 24mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M12 x 50mm & Nut

Machined steel "V" groove wheel, for use with folded angle tracks.

Delivery or in-store pickup available.


More Info
827O 140 Kg 20mm Round Groove Wheel

Wheels

$39.35 (Incl. GST)
827O 140 Kg 20mm Round Groove Wheel

827O 140 Kg 20mm Round Groove Wheel

$39.35 (Incl. GST)

Technical Specifications:

  • Groove Type: 20mm Round Groove
  • Load Capacity: 140 Kg
  • Wheel Diameter: 80mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 26mm
  • Groove Width: 21mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 34mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 60mm & Nut

Machined steel "O" round groove wheels, for use with sliding gate floor track or 20mm bar.

Delivery or in-store pickup available.


More Info
1213 100 Kg 6mm Round Groove Wheel

Wheels

$41.50 (Incl. GST)
1213 100 Kg 6mm Round Groove Wheel

1213 100 Kg 6mm Round Groove Wheel

$41.50 (Incl. GST)

Technical Specifications:

  • Groove Type: 6mm Round Groove
  • Load Capacity: 100 Kg
  • Wheel Diameter: 120mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 13mm
  • Groove Width: 6mm
  • Groove Depth: 7mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 17mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 12mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? No

Machined steel rope groove pulley, suits 6mm wire rope.

Delivery or in-store pickup available.


More Info
1227O 200 Kg 20mm Round Groove Wheel

Wheels

$62.35 (Incl. GST)
1227O 200 Kg 20mm Round Groove Wheel

1227O 200 Kg 20mm Round Groove Wheel

$62.35 (Incl. GST)

Technical Specifications:

  • Groove Type: 20mm Round Groove
  • Load Capacity: 200 Kg
  • Wheel Diameter: 120mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 26mm
  • Groove Width: 21mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 12mm
  • Hub Length (sleeved): 34mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 60mm & Nut

Machined steel "O" round groove wheels, for use with sliding gate floor track or 20mm bar.

Delivery or in-store pickup available.


More Info
1030O 300 Kg 20mm Round Groove Wheel

Wheels

$71.95 (Incl. GST)
1030O 300 Kg 20mm Round Groove Wheel

1030O 300 Kg 20mm Round Groove Wheel

$71.95 (Incl. GST)

Technical Specifications:

  • Groove Type: 20mm Round Groove
  • Load Capacity: 300 Kg
  • Wheel Diameter: 100mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 30mm
  • Groove Width: 21mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 22mm
  • Hub Length (sleeved): 44mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 70mm & Nut

Machined steel "O" round groove wheels, for use with sliding gate floor track or 20mm bar.

Delivery or in-store pickup available.


More Info
1030V 300 Kg V Groove Wheel

Wheels

$71.95 (Incl. GST)
1030V 300 Kg V Groove Wheel

1030V 300 Kg V Groove Wheel

$71.95 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 300 Kg
  • Wheel Diameter: 100mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 30mm
  • Groove Width: 21mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 24mm
  • Hub Length (sleeved): 44mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 70mm & Nut

Machined steel "V" groove wheel, for use with folded angle tracks.

Delivery or in-store pickup available.


More Info
VG-62-BB20 700 Kg V Groove Wheel

Wheels

$81.85 (Incl. GST)
VG-62-BB20 700 Kg V Groove Wheel

VG-62-BB20 700 Kg V Groove Wheel

$81.85 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 700 Kg
  • Wheel Diameter: 150mm
  • Wheel Material: Cast Iron
  • Finish: Painted
  • Tyre Material: Cast Iron
  • Tread Width: 45mm
  • Groove Width: 22mm
  • Groove Depth: 12mm
  • Hub Length (unsleeved): 60mm
  • Hub Length (sleeved): 65mm
  • Bore Diameter (unsleeved): 20mm
  • Sleeved Bore Diameter Options: 12.5mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearings
  • Axle Bolt/Nut Supplied? No

Cast iron "V" groove wheels for running on angle iron tracks.

Download Specifications PDF

Delivery or in-store pickup available.


More Info
1230O 350 Kg 20mm Round Groove Wheel

Wheels

$87.25 (Incl. GST)
1230O 350 Kg 20mm Round Groove Wheel

1230O 350 Kg 20mm Round Groove Wheel

$87.25 (Incl. GST)

Technical Specifications:

  • Groove Type: 20mm Round Groove
  • Load Capacity: 350 Kg
  • Wheel Diameter: 120mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 30mm
  • Groove Width: 21mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 24mm
  • Hub Length (sleeved): 44mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 70mm & Nut

Machined steel "O" round groove wheels, for use with sliding gate floor track or 20mm bar.

Delivery or in-store pickup available.


More Info
1230V 350 Kg V Groove Wheel

Wheels

$87.25 (Incl. GST)
1230V 350 Kg V Groove Wheel

1230V 350 Kg V Groove Wheel

$87.25 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 350 Kg
  • Wheel Diameter: 120mm
  • Wheel Material: Steel
  • Finish: Zinc Plated
  • Tyre Material: Steel
  • Tread Width: 30mm
  • Groove Width: 22mm
  • Groove Depth: 9mm
  • Hub Length (unsleeved): 24mm
  • Hub Length (sleeved): 44mm
  • Bore Diameter (unsleeved): 17mm
  • Sleeved Bore Diameter Options: 14mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearing
  • Axle Bolt/Nut Supplied? M14 x 70mm & Nut

Machined steel "V" groove wheel, for use with folded angle tracks.

Delivery or in-store pickup available.


More Info
VG-82-BB20 900 Kg V Groove Wheel

Wheels

$117.90 (Incl. GST)
VG-82-BB20 900 Kg V Groove Wheel

VG-82-BB20 900 Kg V Groove Wheel

$117.90 (Incl. GST)

Technical Specifications:

  • Groove Type: V Groove
  • Load Capacity: 900 Kg
  • Wheel Diameter: 200mm
  • Wheel Material: Cast Iron
  • Finish: Painted
  • Tyre Material: Cast Iron
  • Tread Width: 45mm
  • Groove Width: 22mm
  • Groove Depth: 12mm
  • Hub Length (unsleeved): 60mm
  • Hub Length (sleeved): 65mm
  • Bore Diameter (unsleeved): 20mm
  • Sleeved Bore Diameter Options: 12.5mm
  • Sleeve Type: Top Hat Pair
  • Bearing Type: Ball Bearings
  • Axle Bolt/Nut Supplied? No

Cast iron "V" groove wheels for running on angle iron tracks.

Download Specifications PDF

Delivery or in-store pickup available.


More Info
