Swivel

BPUQ100BH 140 Kg Black Series Castor Swivel Bolt Hole P/U on Nylon 100mm x 32mm

$21.25 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 140 Kg
• -Brake Type- N/A
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 100mm x 32mm
• -Overall Height- 131mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)- 87mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ100BHTB 140 Kg Black Series Castor Swivel Bolt Hole Total Brake P/U on Nylon 100mm x 32mm

$24.00 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 140 Kg
• -Brake Type- Total Brake
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 100mm x 32mm
• -Overall Height- 131mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)- 111mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ100S 140 Kg Black Series Castor Swivel Plate P/U on Nylon 100mm x 32mm

$21.25 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 140 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 100mm x 32mm
• -Overall Height- 131mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 87mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ100STB 140 Kg Black Series Castor Swivel Plate Total Brake P/U on Nylon 100mm x 32mm

$24.00 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 140 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 100mm x 32mm
• -Overall Height- 131mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 111mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ125BH 155 Kg Black Series Castor Swivel Bolt Hole P/U on Nylon 125mm x 32mm

$24.20 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 155 Kg
• -Brake Type- N/A
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 125mm x 32mm
• -Overall Height- 157mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)-

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ125BHTB 155 Kg Black Series Castor Swivel Bolt Hole Total Brake P/U on Nylon 125mm x 32mm

$28.40 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 155 Kg
• -Brake Type- Total Brake
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 125mm x 32mm
• -Overall Height- 157mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)-

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ125S 155 Kg Black Series Castor Swivel Plate P/U on Nylon 125mm x 32mm

$24.20 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 155 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 125mm x 32mm
• -Overall Height- 157mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)-

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ125STB 155 Kg Black Series Castor Swivel Plate Total Brake P/U on Nylon 125mm x 32mm

$28.40 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 155 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 125mm x 32mm
• -Overall Height- 157mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)-

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ50BH 52 Kg Black Series Castor Swivel Bolt Hole P/U on Nylon 50mm x 26mm

$10.10 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 52 Kg
• -Brake Type- N/A
• -Mounting Type- M10 Pintle
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 50mm x 26mm
• -Overall Height- 75mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- M10 Pintle
• -Swivel Radius (inc. brake if fitted)- 50mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

Delivery or in-store pickup available.

BPUQ50BHTB 52 Kg Black Series Castor Swivel Bolt Hole Total Brake P/U on Nylon 50mm x 26mm

$12.20 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 52 Kg
• -Brake Type- Total Brake
• -Mounting Type- M10 Pintle
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 50mm x 26mm
• -Overall Height- 75mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- M10 Pintle
• -Swivel Radius (inc. brake if fitted)- 76mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

Delivery or in-store pickup available.

BPUQ50S 52 Kg Black Series Castor Swivel Plate P/U on Nylon 50mm x 26mm

$10.10 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 52 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 50mm x 26mm
• -Overall Height- 75mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 71mm x 52mm
• -Mounting Plate Hole Centres- 35mm x 52/55mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 52mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ50STB 52 Kg Black Series Castor Swivel Plate Total Brake P/U on Nylon 50mm x 26mm

$12.20 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 52 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 50mm x 26mm
• -Overall Height- 75mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 71mm x 52mm
• -Mounting Plate Hole Centres- 35mm x 52/55mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 76mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ75BH 115 Kg Black Series Castor Swivel Bolt Hole P/U on Nylon 75mm x 32mm

$17.80 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 115 Kg
• -Brake Type- N/A
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)- 73mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ75BHTB 115 Kg Black Series Castor Swivel Bolt Hole Total Brake P/U on Nylon 75mm x 32mm

$21.35 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 115 Kg
• -Brake Type- Total Brake
• -Mounting Type- 13mm Bolt Hole
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- N/A
• -Mounting Plate Hole Centres- N/A
• -Mounting Plate Hole Diameter- 13mm
• -Swivel Radius (inc. brake if fitted)- 103mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ75S 115 Kg Black Series Castor Swivel Plate P/U on Nylon 75mm x 32mm

$17.80 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 115 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 73mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

BPUQ75STB 115 Kg Black Series Castor Swivel Plate Total Brake P/U on Nylon 75mm x 32mm

$21.35 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 115 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Black Powder Coat
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 65mm
• -Mounting Plate Hole Centres- 45mm x 75/78mm
• -Mounting Plate Hole Diameter- 8.5mm
• -Swivel Radius (inc. brake if fitted)- 103mm

Light industrial decorative castor with a black powder coated finish, wheel is non scratching black polyurethane. Suitable applications include furniture, displays, shop fittings etc.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

CBQ100G/MZP 100 Kg Zinc Castor Swivel Blue Rubber 100mm x 30mm

$29.75 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 30mm
• -Overall Height- 135mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 91mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $29.75 AUD North American - $29.75 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ100G/MZPDL 100 Kg Zinc Castor Swivel Direction Lock Only Blue Rubber 100mm x 30mm

$37.45 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- Direction Only
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 30mm
• -Overall Height- 135mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 128mm

***DIRECTION LOCK ONLY, NO WHEEL LOCK***

When the pedal is engaged the castor will lock in a forward direction to provide dual functionality as either a fixed castor (pedal engaged) or a swivel castor (pedal released). No brake will be applied to the wheel.

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $37.45 AUD North American - $37.45 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ100G/MZPTB 100 Kg Zinc Castor Swivel Total Brake Blue Rubber 100mm x 30mm

$37.45 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 30mm
• -Overall Height- 135mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 128mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $37.45 AUD North American - $37.45 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ125G/MZP 100 Kg Zinc Castor Swivel Blue Rubber 125mm x 30mm

$33.05 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 30mm
• -Overall Height- 161mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 103mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $33.05 AUD North American - $33.05 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ125G/MZPDL 100 Kg Zinc Castor Swivel Direction Lock Only Blue Rubber 125mm x 30mm

$40.75 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- Direction Only
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 30mm
• -Overall Height- 161mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 128mm

***DIRECTION LOCK ONLY, NO WHEEL LOCK***

When the pedal is engaged the castor will lock in a forward direction to provide dual functionality as either a fixed castor (pedal engaged) or a swivel castor (pedal released). No brake will be applied to the wheel.

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $40.75 AUD North American - $40.75 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ125G/MZPTB 100 Kg Zinc Castor Swivel Total Brake Blue Rubber 125mm x 30mm

$40.75 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 30mm
• -Overall Height- 161mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 128mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $40.75 AUD North American - $40.75 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ75G/MZP 85 Kg Zinc Castor Swivel Blue Rubber 75mm x 30mm

$27.55 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 85 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 75mm x 30mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 71mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $27.55 AUD North American - $27.55 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ75G/MZPDL 85 Kg Zinc Castor Swivel Direction Lock Only Blue Rubber 75mm x 30mm

$35.25 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 85 Kg
• -Brake Type- Direction Only
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 75mm x 30mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 128mm

***DIRECTION LOCK ONLY, NO WHEEL LOCK***

When the pedal is engaged the castor will lock in a forward direction to provide dual functionality as either a fixed castor (pedal engaged) or a swivel castor (pedal released). No brake will be applied to the wheel.

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $35.25 AUD North American - $35.25 AUD

Top Plate Option

ISO

North American

---

More Info

CBQ75G/MZPTB 85 Kg Zinc Castor Swivel Total Brake Blue Rubber 75mm x 30mm

$35.25 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 85 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- Blue Rubber
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- Yes
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 75mm x 30mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 118mm

Light industrial blue rubber castor. General use including warehouse trolleys, engineering and furniture.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $35.25 AUD North American - $35.25 AUD

Top Plate Option

ISO

North American

---

More Info

CFQ175/CPH 45 Kg Black Paint Castor Swivel Foamed Urethane 175mm x 45mm

$86.70 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 45 Kg
• -Brake Type- N/A
• -Mounting Type- 12.7mm Bolt-Hole
• -Wheel Material- Foamed Urethane
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Black Paint
• -Wheel Diameter X Tread Width- 175mm x 45mm
• -Overall Height- 225mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 130mm

Wheelchair specific castor. EVA foam wheel non-marking

CFQ200/CPH 45 Kg Black Paint Castor Swivel Foamed Urethane 200mm x 45mm

$93.85 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 45 Kg
• -Brake Type- N/A
• -Mounting Type- 12.7mm Bolt-Hole
• -Wheel Material- Foamed Urethane
• -Wheel Bearing Type- Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Black Paint
• -Wheel Diameter X Tread Width- 200mm x 45mm
• -Overall Height- 237mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 144mm

Wheelchair specific castor. EVA foam wheel non-marking

DCI75/MZP 100 Kg Zinc Castor Swivel Cast Iron 75mm x 32mm

$28.85 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Cast Iron
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 71mm

Light industrial cast iron castor. General use including warehouse trolleys, engineering and furniture.

Also used in oven racks, powder coating trolleys and freezer trolleys.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $28.85 AUD North American - $28.85 AUD

Top Plate Option

ISO

North American

---

More Info

DCI75/MZPHT 100 Kg Zinc Castor - HIGH TEMP Swivel Cast Iron 75mm x 32mm

$33.85 (Incl. GST)

Technical Specifications - HIGH TEMP!

• -Castor Type- Swivel
• -Load Capacity- 100 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Cast Iron
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 75mm x 32mm
• -Overall Height- 106mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 71mm

Light industrial hi/low temp castor. General use including oven racks, powder coating trolleys and freezer trolleys.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $33.85 AUD North American - $33.85 AUD

Top Plate Option

ISO

North American

---

More Info

ECC75 Small Engine Crane Castor Cast Iron 75mm x 40mm

$15.84 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- Not rated!
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Cast Iron
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Mild Steel
• -Wheel Diameter X Tread Width- 75mm x 29mm
• -Overall Height- 99mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 60mm
• -Mounting Plate Hole Centres- 74mm x 30mm
• -Mounting Plate Hole Diameter- 9mm
• -Swivel Radius (inc. brake if fitted)- 68mm

Small engine crane castor used mostly as the centre support of most engine cranes available.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

ECC88 Large Engine Crane Castor Cast Iron 88mm x 40mm

$20.24 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- Not rated!
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- Cast Iron
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Mild Steel
• -Wheel Diameter X Tread Width- 88mm x 29mm
• -Overall Height- 115mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 95mm x 60mm
• -Mounting Plate Hole Centres- 74mm x 30mm
• -Mounting Plate Hole Diameter- 9mm
• -Swivel Radius (inc. brake if fitted)- 71mm

Large engine crane castor used mostly as the rear or front leg support of most engine cranes available.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

EPS025WN 9 Kg Chrome Castor Swivel White Nylon 25mm x 12mm

$3.30 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 9 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- White Nylon
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Chrome
• -Wheel Diameter X Tread Width- 25mm x 12mm
• -Overall Height- 36mm
• -Axle Type- Rivet
• -Mounting Plate Dimensions- 34mm x 30mm
• -Mounting Plate Hole Centres- 28mm x 23mm
• -Mounting Plate Hole Diameter- 4mm
• -Swivel Radius (inc. brake if fitted)- 22mm

Plate mounted light duty chrome plated castor fitted with white nylon wheel. General use for lighter loads requiring low mount height.

Delivery or in-store pickup available.

EPS032WN 16 Kg Chrome Castor Swivel White Nylon 32mm x 14mm

$4.95 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 16 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- White Nylon
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Chrome
• -Wheel Diameter X Tread Width- 32mm x 14mm
• -Overall Height- 42mm
• -Axle Type- Rivet
• -Mounting Plate Dimensions- 38mm x 32mm
• -Mounting Plate Hole Centres- 30mm x 24mm
• -Mounting Plate Hole Diameter- 4mm
• -Swivel Radius (inc. brake if fitted)- 27mm

Plate mounted light duty chrome plated castor fitted with white nylon wheel. General use for lighter loads requiring low mount height.

Delivery or in-store pickup available.

EPS038WN 25 Kg Chrome Castor Swivel White Nylon 38mm x 16mm

$5.75 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 25 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- White Nylon
• -Wheel Bearing Type- Plain
• -Thread guard Fitted?- No
• -Frame Finish- Chrome
• -Wheel Diameter X Tread Width- 38mm x 16mm
• -Overall Height- 50mm
• -Axle Type- Rivet
• -Mounting Plate Dimensions- 45mm x 38mm
• -Mounting Plate Hole Centres- 35mm x 28mm
• -Mounting Plate Hole Diameter- 5mm
• -Swivel Radius (inc. brake if fitted)- 31mm

Plate mounted light duty chrome plated castor fitted with white nylon wheel. General use for lighter loads requiring low mount height.

Delivery or in-store pickup available.

HIN4S-CIPU 280 Kg Zinc Castor Swivel P/U on Cast Iron 100mm x 50mm

$35.85 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 280 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 50mm
• -Overall Height- 144mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 81mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN4SB-CIPU 280 Kg Zinc Castor Swivel Total Brake P/U on Cast Iron 100mm x 50mm

$44.65 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 280 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 50mm
• -Overall Height- 144mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 129mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN5S-CIPU 350 Kg Zinc Castor Swivel P/U on Cast Iron 125mm x 50mm

$38.95 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 350 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 50mm
• -Overall Height- 165mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 96mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN5SB-CIPU 350 Kg Zinc Castor Swivel Total Brake P/U on Cast Iron 125mm x 50mm

$47.30 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 350 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 50mm
• -Overall Height- 165mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 129mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN6S-CIPU 400 Kg Zinc Castor Swivel P/U on Cast Iron 150mm x 50mm

$43.65 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 400 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 150mm x 50mm
• -Overall Height- 191mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 115mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN6SB-CIPU 400 Kg Zinc Castor Swivel Total Brake P/U on Cast Iron 150mm x 50mm

$57.30 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 400 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 150mm x 50mm
• -Overall Height- 191mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 141mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN8S-CIPU 450 Kg Zinc Castor Swivel P/U on Cast Iron 200mm x 50mm

$57.10 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 450 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 50mm
• -Overall Height- 242mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 150mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HIN8SB-CIPU 450 Kg Zinc Castor Swivel Total Brake P/U on Cast Iron 200mm x 50mm

$69.20 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 450 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Cast Iron
• -Wheel Bearing Type- Precision Ball Bearing
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 200mm x 50mm
• -Overall Height- 242mm
• -Axle Type- Bolted
• -Mounting Plate Dimensions- 114mm x 100mm
• -Mounting Plate Hole Centres- 85mm x 72mm
• -Mounting Plate Hole Diameter- 11mm
• -Swivel Radius (inc. brake if fitted)- 150mm

Economy heavy duty castor, polyurethane on cast iron wheel fitted with precision ball bearings. Suitable for work benches, heavy trolleys, workshop equipment.

-<--- DON'T FORGET YOUR MOUNTING HARDWARE!

Delivery or in-store pickup available.

HUR100/OZP 300 Kg Zinc Castor Swivel P/U on Nylon 100mm x 40mm

$60.40 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 300 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 40mm
• -Overall Height- 138mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 96mm

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $60.40 AUD North American - $60.40 AUD

Top Plate Option

ISO

North American

---

More Info

HUR100/OZPDL 300 Kg Zinc Castor Swivel Direction Lock Only P/U on Nylon 100mm x 40mm

$71.40 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 300 Kg
• -Brake Type- Direction Only
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 40mm
• -Overall Height- 138mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 140mm

***DIRECTION LOCK ONLY, NO WHEEL LOCK***

When the pedal is engaged the castor will lock in a forward direction to provide dual functionality as either a fixed castor (pedal engaged) or a swivel castor (pedal released). No brake will be applied to the wheel.

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $71.40 AUD North American - $71.40 AUD

Top Plate Option

ISO

North American

---

More Info

HUR100/OZPTB 300 Kg Zinc Castor Swivel Total Brake P/U on Nylon 100mm x 40mm

$71.40 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 300 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 100mm x 40mm
• -Overall Height- 138mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 140mm

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $71.40 AUD North American - $71.40 AUD

Top Plate Option

ISO

North American

---

More Info

HUR125/OZP 350 Kg Zinc Castor Swivel P/U on Nylon 125mm x 40mm

$62.70 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 350 Kg
• -Brake Type- N/A
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 40mm
• -Overall Height- 162mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 109mm

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $62.70 AUD North American - $62.70 AUD

Top Plate Option

ISO

North American

---

More Info

HUR125/OZPDL 350 Kg Zinc Castor Swivel Direction Lock Only P/U on Nylon 125mm x 40mm

$73.70 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 350 Kg
• -Brake Type- Direction Only
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 40mm
• -Overall Height- 162mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 140mm

***DIRECTION LOCK ONLY, NO WHEEL LOCK***

When the pedal is engaged the castor will lock in a forward direction to provide dual functionality as either a fixed castor (pedal engaged) or a swivel castor (pedal released). No brake will be applied to the wheel.

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $73.70 AUD North American - $73.70 AUD

Top Plate Option

ISO

North American

---

More Info

HUR125/OZPTB 350 Kg Zinc Castor Swivel Total Brake P/U on Nylon 125mm x 40mm

$73.70 (Incl. GST)

Technical Specifications

• -Castor Type- Swivel
• -Load Capacity- 350 Kg
• -Brake Type- Total Brake
• -Mounting Type- Plate
• -Wheel Material- P/U on Nylon
• -Wheel Bearing Type- Needle Roller
• -Thread guard Fitted?- No
• -Frame Finish- Zinc
• -Wheel Diameter X Tread Width- 125mm x 40mm
• -Overall Height- 162mm
• -Axle Type- Bolted
• -Swivel Radius (inc. brake if fitted)- 140mm

Heavy Industrial polyurethane castor. General use including heavier trolleys, engineering, transport and workshops.

Related Options...

MAKE SURE TO SELECT YOUR DESIRED TOP PLATE SIZE BELOW!

ISO - $73.70 AUD North American - $73.70 AUD

Top Plate Option

ISO

North American

---

More Info
